Stage 1 BMW M50 S50 M52 S52 M54 S54 BMW N54 GS6 53BZ 135i 335i 535i 240mm 9 45 7150g 15 76lb

Adapter for integrating BMW M50, M52, M54, S50, S52, S54 engines with a ZF GS6-53BZ 6-speed manual gearbox, originally from BMW N54 models such as the 135i, 335i, and 535i. The adapter includes a flywheel weighing 7150g (15.76lb), which is 60% lighter than the original, enhancing engine response.

Technical Specifications:

• Engine Compatibility: BMW M50, M52, M54, S50, S52, S54
• Gearbox Compatibility: ZF GS6-53BZ from BMW N54 series
• Flywheel Weight: 7150g / 15.76lb
• Flywheel Diameter: 240mm / 9.45"
• Maximum Torque: 650Nm / 479.25 lb-ft
• Included Clutch Set: Sachs XTend 3000 951 952
• Spline Dimensions: 32.5x35-26N, with 26 splines
• Self-adjusting Clutch: Yes
• Replaceable Friction Surface: Yes
• Application: Suitable for both motorsport and daily use

Installation Guidelines:

The installation process is largely plug-and-play; however, modification of the two upper holes on the GS6-53BZ gearbox is required for proper fitment. This adjustment does not impact the alignment between the engine and gearbox. The BMW OE starter motor from M50, S50, M52, S52, M54, and S54 engines remains compatible. The adapter is designed to work with M57N/M57N2/N54/B58 Sachs Performance clutch pressure plates. Clutches from manufacturers such as ACT, Spec, and Tanaci can be utilized with this kit, provided they are compatible with the BMW OE flywheel.

Additional Details:

This product is engineered for motorsport applications and should be installed by qualified professionals in specialized workshops. It meets the standards of ISO PN-EN ISO 9001:2015 certification, and each component is marked with a unique production Seriesl number. Manufactured in Poland, the product ensures high quality through the use of certified materials and advanced CNC machining techniques.

This product is intended for racing use only. DriftParts is not liable for improper installation or misuse.
