Drilling Template ZF 8HP70 Jaguar Diesel GM Chevrolet V8 LS

PMC Motorsport Drilling Template for GM Chevrolet V8 LS Flywheel to ZF 8HP70 Jaguar Diesel Torque Converter (4-bolt)

This drilling template is engineered for precise adaptation of GM Chevrolet LS series engines to Jaguar ZF 8HP transmissions, specifically the ZF 8HP70 8-speed model with a 4-bolt torque converter.

The template is compatible with the following GM Chevrolet V8 LS engine models:

• GM 5.7 Liter V8 Small Block Chevrolet LS1
• GM 6.0 Liter V8 Small Block Chevrolet LS2
• GM 6.2 Liter V8 Small Block Chevrolet LS3
• GM 5.7 Liter V8 Small Block Chevrolet LS6
• GM 7.0 Liter V8 Small Block Chevrolet LS7
• GM Chevrolet LSA
• GM Small Block Chevrolet Vortec (4800, 5300, 6000, 6200)

This product facilitates the adaptation process required for integrating a GM Chevrolet V8 LS flywheel with a ZF 8HP70 Jaguar Diesel Torque Converter, making it particularly suitable for motorsport and high-performance vehicle builds that demand such configurations.

Technical specifications include:

• OEM Reference: Chevrolet LS OE 12580709
• Required Gearbox Adapter: F0JAG-LS
• EAN: 5903707405435
• Product Code: AK0JAG-LS

The drilling template is designed to ensure precise alignment and compatibility, providing seamless integration into the specified engine and transmission systems.

This product is intended for racing use only. DriftParts is not liable for improper installation or misuse.
